Diatone Mamba Stack F405 MK2 3-6S Flight Controller 40A ESC Combo AIO
Sold Out
Brand: Diatone
Amps: 40A
BEC: Yes
Configuration: Stack
CPU: F4
Mounting: 30.5x30.5
OSD: Yes
Take your drone to the next level with the Mamba F405 FC MK2 and Mamba F40 ESC Mk2 bundle. Engineered for precision and performance, the Mamba F405 FC MK2 features a robust STM32F405 MCU and MPU6000 gyro, ensuring stability and reliability even in the most demanding flight conditions. With an input voltage range of 3-6S and dual BEC outputs (5V/2A & 9V/2A), this flight controller provides ample power for your aircraft's systems. Accompanying the FC is the Mamba F40 ESC Mk2, boasting an input voltage range of 3-6S and a max continuous current of 40A, with a burst current capability of up to 50A for rapid acceleration. Both components are lightweight and easy to install, with mounting holes compatible with standard 30.5x30.5mm M3 configurations. Enhance your drone's capabilities with this powerful and reliable FC and ESC combo.
Mamba F405 FC MK2 Specifications:
- Input Voltage: 3-6S (12.6-25V)
- BEC: 5V/2A & 9V/2A
- MCU: STM32F405
- Gyro: MPU6000
- Flash: 16MB
- OSD: AT7456E
- Mounting hole: 30.5x30.5mm, M3
- Weight: 6g
Mamba F40 ESC Mk2 Specifications:
- Input Voltage: 3-6S (12.4V~25V)
- Max. Continuous Current: 40A
- Max Burst Current: 50A (6 sec.)
- BEC: NO
- Mounting: 30.5x30.5mm, M3
- Weight: 10g
Package Contents:
- 1x Mamba F405 Mk2 FC
- 1x Mamba F40 Mk2 ESC
- 1x Mounting Hardware Set
- 1x User Manual (Each for FC and ESC)
