MG90D Digital Micro Full Metal Gear Servo Motor 2.5kg Torque 180 Degree Range
MG90D Digital Micro Full Metal Gear Servo Motor 2.5kg Torque 180 Degree Range
The MG90D Servo epitomizes rapid response, precision, and durability, thanks to its cutting-edge design and all-metal gear construction. Engineered to deliver lightning-fast reactions, this servo boasts an impressive no-load speed of 0.12 sec/60 Degrees, ensuring immediate and precise movements in any situation. Whether you're piloting an RC vehicle through tight corners or fine-tuning the movements of a robotic arm, the MG90D responds with unparalleled agility and accuracy, giving you complete control over your projects.
Built to withstand the rigors of continuous use, the MG90D features a robust all-metal gear construction, providing unmatched durability and resilience. From high-speed maneuvers to heavy-duty tasks, these gears ensure smooth operation and long-lasting performance, even in the most demanding environments. Whether you're tackling challenging terrain or enduring harsh conditions, you can trust the MG90D to deliver consistent and reliable performance, every time. With its combination of rapid response, precision, and all-metal gear construction, the MG90D Servo sets the standard for excellence in servo technology, empowering you to push the boundaries of what's possible in your projects.
Specifications:
Built to withstand the rigors of continuous use, the MG90D features a robust all-metal gear construction, providing unmatched durability and resilience. From high-speed maneuvers to heavy-duty tasks, these gears ensure smooth operation and long-lasting performance, even in the most demanding environments. Whether you're tackling challenging terrain or enduring harsh conditions, you can trust the MG90D to deliver consistent and reliable performance, every time. With its combination of rapid response, precision, and all-metal gear construction, the MG90D Servo sets the standard for excellence in servo technology, empowering you to push the boundaries of what's possible in your projects.
Specifications:
- Dimensions: 22.4 x 12.1 x 22.8 mm (L x W x H)
- Maximum Rotation Angle: 180 Degrees ± 2 Degrees
- Output Shaft: 20-Tooth, Diameter: 4.9mm
- Gear Material: Metal Alloy
- Operating Voltage Range: 4.8V - 6V
- Speed at No Load: 0.12 sec/60 Degrees
- No-load Current Consumption: 90mA/6V
- Stall Torque: 2.2 Kg-cm/6V
- Stall Current: 860mA ± 10%
- Standby Current: 5mA - 6mA
- Control Signal: Pulse Width Modulation (PWM)
- Control System: Analog Control
- Midpoint Position: 1500usec
- Pulse Width Range: 500 - 2500usec
- 1x MG90D Metal Gear Servo
