Flexible GPS Antenna 915MHz 34x1mm (150mm IPEX Connector)

The Pulse Electronics ANTX150P118B09153 is a compact 915MHz flexible PCB antenna designed for cellular, GSM, UMTS, NB-IoT, and LTE applications. Its adhesive backing allows for convenient internal mounting, while the 150mm RF1.13 coaxial cable and IPEX MHF connector provide flexible installation options.

This passive linear-polarized antenna offers up to 1.9dB gain and operates across the 890MHz to 925MHz frequency range. Its slim I-Bar design makes it ideal for space-constrained wireless devices, telemetry systems, IoT equipment, and other 900MHz applications.

Specifications:

• Manufacturer: Pulse Electronics
• Manufacturer Part Number: ANTX150P118B09153
• Antenna Type: Flexible PCB Antenna
• Frequency Range: 890MHz to 925MHz
• Nominal Frequency: 915MHz
• Gain: 1.9dB
• Impedance: 50 Ohms
• VSWR: 2.5:1
• Polarization: Linear
• Number of Bands: 1
• Maximum Power: 1W
• Connector: IPEX MHF
• Cable Type: RF1.13 Coaxial Cable
• Cable Length: 150mm
• Mounting Type: Adhesive Mount
• Antenna Dimensions: 34 x 7 x 0.8mm
• Operating Temperature: -40°C to 85°C

Package Contents:

• 1x Pulse Electronics 915MHz Flexible PCB Antenna with 150mm Cable
